Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X100S
The AirTAC Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X100S is a genuine HLF slide-table cylinder, 20 mm bore: a double-acting dual-rod air cylinder integrated with a low-height cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 125.6 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidelow-height cross-roller guide
- Bore20 mm
- Push thrust @0.5 MPa125.6 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X100S
The AirTAC HLF20X100S is a double-acting dual-rod slide-table cylinder with a 20 mm bore and 100 mm stroke. It integrates a low-height cross-roller linear guide into a compact body, giving the moving table precise straight-line travel with minimal deflection. The dual rods double the thrust compared with a single-rod design, and a floating joint spares the rods from side torque so the guide stays accurate over long strokes. The HLF body is intentionally low-profile, making it ideal where vertical clearance is tight.
This is a genuine AirTAC part with a standard magnet for position sensing; compatible sensor switches include CMSH, DMSH, and EMSH series, which seat in the body's magnetic-switch slots. Thread type is PT. We confirm exact thrust, dimensions, allowable load, and moment values from the AirTAC datasheet or on-page specification table on request.
Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X100S Technical Specifications
| Model | Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X100S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLF (low-height cross-roller guide) |
| Bore | 20 mm |
| Push thrust @0.5 MPa | 125.6 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose the 20 mm bore when you need moderate-to-higher thrust from a low-profile body; a larger bore always provides more push. The HLF sub-family uses a cross-roller guide in a reduced-height body, making it the right pick when vertical clearance is tight but you still need cross-roller precision and rigidity. The 100 mm stroke is within the HLF20 stroke range. Thread type on this unit is PT. For allowable load, moment, and kinetic-energy limits, we confirm sizing from the published AirTAC tables and deflection curves on request.
Applications
Long-Travel Pick-and-Place
The 100 mm stroke and low-height cross-roller guide suit reaching across a wider span to pick parts from one station and place them at another with precise positioning.
Transfer Between Conveyor Lanes
Use the guided 100 mm travel to push small workpieces laterally between parallel conveyor lanes where vertical clearance above the belt is limited.
Low-Clearance Assembly Stage
The reduced body height lets the slide table mount under a tight fixture or overhead mechanism, guiding a 20 mm bore move for part insertion or pressing.
FAQ
What makes the HLF20X100S different from other AirTAC slide-table models?
The HLF prefix means this is a low-height cross-roller slide table with a 20 mm bore and 100 mm stroke. The cross-roller guide provides high rigidity and precision, while the reduced body height is designed for installations where vertical clearance is limited. It is double-acting with dual rods and a floating joint. Thread type is PT.
What is the maximum operating pressure for the HLF20X100S?
