Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X10S
The AirTAC Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X10S is a genuine HLF slide-table cylinder, 20 mm bore: a double-acting dual-rod air cylinder integrated with a low-height cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 125.6 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidelow-height cross-roller guide
- Bore20 mm
- Push thrust @0.5 MPa125.6 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X10S
The AirTAC HLF20X10S is a double-acting dual-rod slide-table cylinder with a 20 mm bore and 10 mm stroke. It pairs an air cylinder with a low-height cross-roller linear guide for precise straight-line travel with very low deflection. The dual rods double the thrust versus a single-rod cylinder, and the floating joint prevents side torque from loading the rods. The compact, low-profile HLF body suits installations where vertical space is limited.
This genuine AirTAC part carries a standard magnet for position detection; CMSH, DMSH, and EMSH sensor switches fit the body's integrated slots. Thread type is PT. We verify thrust, dimensions, allowable load, and moment ratings against the AirTAC datasheet or on-page table on request.
Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X10S Technical Specifications
| Model | Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X10S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLF (low-height cross-roller guide) |
| Bore | 20 mm |
| Push thrust @0.5 MPa | 125.6 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Select the 20 mm bore for moderate-to-higher thrust in a low-profile package; bigger bores give more push. The HLF cross-roller guide in its reduced-height body is ideal where you need cross-roller precision but have limited vertical space. The 10 mm stroke suits short-travel positioning tasks. Thread type is PT. We verify allowable load, moment, and deflection values from the AirTAC datasheet tables and curves on request.
Applications
Gripper Traverse
The 10 mm stroke moves a gripper a short, precise distance to engage and release small components, with the cross-roller guide keeping the jaw travel straight.
Mini Stopper Gate
Use the short 10 mm guided stroke as a compact stopper that extends and retracts to hold or release parts at a machining station in a low-height assembly.
Indexing Pin Position
The low-profile body and short stroke suit driving an indexing pin in and out of a fixture plate where overhead clearance is constrained.
FAQ
How do I choose between HLF and other AirTAC slide-table sub-families?
Choose HLF when you need a cross-roller guide for precision and rigidity but also need a reduced body height for tight vertical clearance. The HLF20X10S has a 20 mm bore and 10 mm stroke, giving moderate-to-higher thrust in a compact package. HLS uses a cross-roller guide at standard height, HLQ uses ball bearings, and HLH uses a miniature roller-ball guide.
Can the HLF20X10S handle heavy side loads?
The cross-roller guide provides good rigidity and deflection resistance, but allowable load, moment, and kinetic-energy limits are specific to the bore and stroke. Maximum working pressure is 0.7 MPa. We confirm the exact load, moment, and deflection values from the published AirTAC tables and curves on request so you can size with confidence.
