Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X75S
The AirTAC Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X75S is a genuine HLF slide-table cylinder, 20 mm bore: a double-acting dual-rod air cylinder integrated with a low-height cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 125.6 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidelow-height cross-roller guide
- Bore20 mm
- Push thrust @0.5 MPa125.6 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X75S
The AirTAC HLF20X75S is a double-acting dual-rod slide-table cylinder that integrates an air cylinder with a low-height cross-roller linear guide. The cross-roller guide delivers high rigidity and precise straight-line travel while the reduced body height suits tight-clearance installations. A floating joint protects the rods from side torque, and the dual-rod design doubles the thrust for a bore 20 actuator at a 75 mm stroke.
This is a genuine AirTAC part with a standard magnet for position sensing. Compatible sensor switches include CMSH, DMSH, and EMSH series, which mount in the body slots. We confirm exact thrust values, overall dimensions, allowable load, and moment data from the AirTAC datasheet or on-page spec table on request.
Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X75S Technical Specifications
| Model | Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF20X75S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLF (low-height cross-roller guide) |
| Bore | 20 mm |
| Push thrust @0.5 MPa | 125.6 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose the HLF sub-family when you need cross-roller precision in a low-profile body. Bore 20 provides higher thrust than smaller bores; select the bore by your required push force and verify the exact thrust from the spec table. Stroke 75 mm falls within the bore 20 stroke range. The HLF has two port groups for flexible plumbing and no adjuster option; thread is PT standard. We can route load and moment sizing to the published tables and deflection curves for your application.
Applications
Pick-and-Place Head Traverse
Mounts a gripper or vacuum head for precise horizontal part placement where low body height frees overhead clearance.
Small-Parts Assembly Stage
Positions a workpiece or tooling carrier against a stop with cross-roller repeatability in a compact fixture.
Transfer Shuttle Between Belts
Shuttles small components between two conveyor lanes with straight guided travel and minimal deflection at the 75 mm stroke.
FAQ
What guide type does the HLF20X75S use and how does it differ from HLS?
The HLF uses an integrated cross-roller guide like the HLS, but in a low-height body with two port groups instead of one. Both deliver high rigidity and precise travel; the HLF trades some body height for a clearance advantage. The HLF has no adjuster or shock-absorber option.
What is the maximum operating pressure for the HLF20X75S?
Maximum working pressure is 0.7 MPa (100 psi). The operating range for bore 20 is 0.15 to 0.7 MPa (22 to 100 psi). We confirm allowable load and moment values from the AirTAC datasheet on request.
