Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF8X10S
The AirTAC Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF8X10S is a genuine HLF slide-table cylinder, 8 mm bore: a double-acting dual-rod air cylinder integrated with a low-height cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 20.1 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidelow-height cross-roller guide
- Bore8 mm
- Push thrust @0.5 MPa20.1 N
- Operating pressure0.2 - 0.7 MPa (29 - 100 psi)
- Port sizeM3x0.5
- CushionBumper
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF8X10S
The AirTAC HLF8X10S is a double-acting dual-rod slide-table cylinder with a bore of 8 mm and a 10 mm stroke. It integrates an air cylinder with a low-height cross-roller linear guide, combining precise straight-line travel with a compact body profile. The floating joint prevents side torque on the rods, and the dual-rod design doubles thrust for the bore size.
This genuine AirTAC part includes a standard magnet for position detection. CMSH, DMSH, and EMSH sensor switches fit the magnetic-switch slots on the body. We verify thrust, dimensions, allowable load, and moment from the AirTAC datasheet or on-page table on request.
Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF8X10S Technical Specifications
| Model | Airtac HLF Ultra-Slim Precision Slide Table Cylinder HLF8X10S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLF (low-height cross-roller guide) |
| Bore | 8 mm |
| Push thrust @0.5 MPa | 20.1 N |
| Port size | M3x0.5 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 0.7 MPa (29 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The HLF sub-family suits applications needing cross-roller precision in a low-height envelope. Bore 8 provides light thrust; select a larger bore if you need more push force. Stroke 10 mm stays within the bore 8 stroke range. Thread is PT standard, and the HLF offers two port groups but no adjuster option. Route load and moment sizing to the published tables and deflection curves.
Applications
Gripper Traverse in Tight Cell
Moves a small gripper across a short 10 mm stroke where low body height is needed in a compact work cell.
Miniature Stopper Positioner
Positions a stop or gate pin precisely with cross-roller guidance in a space-limited fixture.
Short-Stroke Part Transfer
Transfers small components horizontally between stations with guided straight travel at minimal deflection.
FAQ
Does the HLF8X10S come with a magnet?
Yes, the S in HLF8X10S means a magnet is fitted as standard across the entire HLF line. It is not an optional add-on. Compatible sensor switches are CMSH, DMSH, and EMSH.
What pressure range applies to the HLF8X10S?
For bore 8 the operating pressure range is 0.2 to 0.7 MPa (29 to 100 psi). Maximum working pressure is 0.7 MPa. Speed should be controlled with meter-out flow and kept within 50 to 500 mm/s.
