Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100S
$344.52
Regular price
$352.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X100S
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation notes:
Ensure guide rails are parallel within 0.05mm/m alignment tolerance. Use flexible couplings when connecting to driven components. For vertical mounting, install counterbalance valves if holding position during power loss is critical.
AirTAC HLQL12X100S Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X100S
- Type: Dual-axis guided precision slide cylinder (rodless type)
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.7 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Guide rail: Dual chrome-plated steel shafts (Ø8mm)
- Repeat positioning accuracy: ≤±0.01mm
- Max thrust: 34N at 0.5MPa
- Max speed: 500mm/s
- Temperature range: -20℃ to 80℃
- Seal material: Heat-resistant NBR
- Port size: M5x0.8 (Rc1/8 adaptor included)
- Lubrication: Pre-lubricated (Daphne grease AL-2)
- Weight: 0.65kg (excluding accessories)
- Dimensions: 160mm(L) × 40mm(W) × 35mm(H)
High-rigidity dual-axis cylinder with integrated linear guide mechanism, designed for precision linear motion applications. Features chrome-plated piston rods with wiper seals for dust protection. The aluminum alloy body minimizes weight while maintaining structural stability. Compatible with vacuum pick-and-place systems through optional end-port modification.
Typical Applications:
- Semiconductor wafer handling robots
- Precision optical alignment stages
- Automated test equipment positioners
- Pharmaceutical blister packaging machines
- 3C product assembly automation
Installation notes:
Ensure guide rails are parallel within 0.05mm/m alignment tolerance. Use flexible couplings when connecting to driven components. For vertical mounting, install counterbalance valves if holding position during power loss is critical.
Performance Optimization:
- Maintain air quality: ISO 8573-1 Class 2.4.2 (40μm filtration)
- Reduce vibration: Install pulse damper when using high-speed (>300mm/s) reciprocation
- Prevent stick-slip: Apply light oil (ISO VG32) monthly in dry environments
| Property | Property Value |
|---|---|
| sku | HLQL12X100S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
