Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SA
The AirTAC Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SA is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SA
The AirTAC HLQL12X100SA is a symmetrical double-acting dual-rod slide-table cylinder with a ball-bearing linear guide, giving the moving table straight, low-deflection travel. The 12 mm bore and 100 mm stroke provide moderate thrust for compact guided-slide tasks, the dual rod doubles thrust, and a floating joint prevents side torque on the rod. The symmetrical body layout is ideal where a centred, mirrored footprint is needed. The A adjuster adds adjustable rubber stoppers at both ends for finer end-of-stroke control beyond the standard bumper.
This is a genuine AirTAC part with a standard magnet for position sensing; compatible switches are CMSH, DMSH, and EMSH fitted into the body slots. We confirm exact thrust, dimensions, allowable load, and moment data from the AirTAC datasheet or the on-page specification table on request.
Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SA Technical Specifications
| Model | Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQL (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
A 12 mm bore gives moderate guided thrust; for higher force, step up to a 16 or 20 mm bore in the HLQL range. The ball-bearing guide is chosen for anti-rust and dust-proof operation, and the symmetrical HLQL body suits centred layouts. The A adjuster provides adjustable rubber stoppers at both extension and retraction ends, useful when you need end-position tuning beyond the basic bumper. The 100 mm stroke is within the standard range for this bore. Thread is PT; G or NPT variants are listed under separate codes. Load and moment sizing should be verified with us using the published AirTAC tables and deflection curves.
Applications
Small-Parts Transfer
Transfers small components between assembly stations with adjustable rubber stoppers fine-tuning the end positions over the 100 mm ball-guided stroke.
Pick-and-Place Traverse
Carries a gripper across a short horizontal path where the symmetrical body and adjustable stops ensure repeatable end-of-travel positioning.
Gripper Index Stage
Indexes a gripper assembly into position with moderate dual-rod thrust and rubber stoppers that soften and tune the end-of-stroke impact.
FAQ
What does the A suffix in HLQL12X100SA mean?
The A suffix indicates adjustable rubber stoppers at both the extension and retraction ends. This gives you end-of-stroke position tuning on both sides, whereas the basic model uses fixed bumper cushions only.
Is the magnet optional on this model?
No. The S in the model code means the magnet is standard and always fitted. The entire HLQL line is magnet-equipped for use with CMSH, DMSH, or EMSH sensor switches installed in the body slots.
