Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SAF
AirTAC HLQL12X100SAF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X100SAF
- Type: Dual-axis guided slide cylinder (precision linear motion)
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Structure: Twin-rail guide with 4 precision linear bearings
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Square/flange mounting (ISO 15552 compatible)
- Guide shafts: Hardened stainless steel Ø8mm (HRC58-62)
- Repeat accuracy: ±0.01mm
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Seal material: NBR/PU hybrid seals (FDA compliant option available)
- Protection rating: IP40 (IP67 with optional wiper kit)
- Weight: 0.82kg (excluding accessories)
- Dimensions: 140mm(L) × 42mm(W) × 60mm(H) (at mid-stroke)
High-rigidity dual-axis cylinder with integrated linear guide system, designed for ultra-precise positioning in multi-axis applications. Features zero-lash ball bushing guides and hardened shaft treatment for minimal wear. The dual piston design eliminates rotational torque, achieving ≤0.01° angular deviation under load. Requires ISO 8573-1:2010 Class 3 compressed air.
- Semiconductor wafer handling robots
- Optical lens coating equipment
- Medical PCR testing automation
- High-speed pick-and-place systems (up to 2m/s)
- Precision dispensing machines
- Laboratory sample positioning stages
Installation note:
Use torque-controlled mounting (1.2-1.5Nm for M5 screws). Maintain 0.02mm/m alignment tolerance between guide rails.
Lubricate with ISO VG32 hydraulic oil before initial operation. Avoid lateral forces exceeding 35N.
| Property | Property Value |
|---|---|
| sku | HLQL12X100SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
