Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SB
$416.65
Regular price
$424.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X100SB
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Maintain parallelism within 0.05mm between guide rods during alignment.
Use torque-controlled screws (0.7-1.0N·m) for mounting. Allow 1.5mm thermal
expansion margin per 100mm at >60℃ environments.
AirTAC HLQL12X100SB Dual-Axis Precision Slide Table Cylinder Specifications
- Model: HLQL12X100SB
- Type: Dual-axis guided precision cylinder
- Bore size: Ø12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Base mounting with 4x M4 threaded holes
- Repeat positioning accuracy: ±0.01mm
- Max speed: 800mm/s (with cushion)
- Load capacity: 3.5N·m moment / 20N lateral load
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (PPS grease)
- Material: Aluminum alloy body with hard anodized guide rods
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54
- Weight: 0.82kg (excluding accessories)
- Dimensions: 200mm(L) × 40mm(W) × 30mm(H) (full extension)
A high-precision dual-axis cylinder combining pneumatic actuation with linear guide technology. Features zero-backlash needle roller bearings and chromium-plated piston rod (HRC45 hardness). The T-slot design allows direct mounting of sensors or tooling plates. Requires 5μm filtered air and operates optimally at 0.5 MPa.
Typical Applications:
- Semiconductor wafer handling robots
- Precision optical lens positioning systems
- Medical device assembly automation
- PCB inspection equipment stages
- Micro-dispensing machine Z-axis control
Installation note:
Maintain parallelism within 0.05mm between guide rods during alignment.
Use torque-controlled screws (0.7-1.0N·m) for mounting. Allow 1.5mm thermal
expansion margin per 100mm at >60℃ environments.
| Property | Property Value |
|---|---|
| sku | HLQL12X100SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
