Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SBF
AirTAC HLQL12X100SBF Dual-Axis Precision Slide Table Cylinder Specifications
- Model: HLQL12X100SBF
- Type: Dual-axis guided precision cylinder
- Bore size: Ø12mm
- Stroke: 100mm (customizable 10-500mm)
- Shaft type: Double chrome-plated stainless steel rods
- Mounting: Side-mount & base-mount compatibility
- Operating pressure: 0.05-0.9 MPa (7-130 psi)
- Cushioning: Adjustable air cushion at both ends
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Rod end material: SUS304 stainless steel
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston speed: 50-700mm/s (lubricated)
- Lubrication: Oil mist lubrication recommended (ISO VG32)
- Protection rating: IP54 (standard dust/water resistance)
- Weight: 1.45kg ±2%
- Dimensions: 156mm(L) × 42mm(W) × 42mm(H)
High-rigidity dual-axis guided cylinder with integrated linear guide rails, designed for precision linear motion applications. Features low-friction seals (PU material) and cross-roller bearing support for minimal deflection under side loads. Includes magnetic piston for position sensing compatibility (sensor not included). Requires filtered air with 5-40μm filtration accuracy.
- PCB component insertion machines
- Optical lens alignment systems
- Micro-dispensing equipment
- Semiconductor wafer handling
- Precision fixture positioning
- 3D measurement probe movement
Installation note:
Align guide rails within 0.05mm/m parallelism tolerance during mounting.
Use torque-controlled fasteners (1.2N·m max for M5 screws).
Perform 50-100 break-in cycles at 0.3MPa before full-load operation.
| Property | Property Value |
|---|---|
| sku | HLQL12X100SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
