Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X100SBS
$384.08
Regular price
$391.58
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X100SBS
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation notes:
Lubricate guide shafts with ISO VG32 hydraulic oil before initial use.
Maximum side load capacity 15N. For vertical installations,
maintain ≤0.5mm/m alignment tolerance between guide rods and load.
AirTAC HLQL12X100SBS Double-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X100SBS
- Type: Double-axis guided precision slide cylinder
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Side-mount with 4x M3 threaded holes
- Guide rod material: Stainless steel SCS14 (chrome-plated)
- Piston rod material: SUJ2 bearing steel (hard chrome-plated)
- Seal material: NBR + PU hybrid seals
- Port size: M5x0.8 (dual ports at both ends)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Weight: 0.85kg (excluding accessories)
- Dimensions: 230mm(L) × 42mm(W) × 42mm(H)
High-rigidity dual-axis cylinder with integrated linear guides, designed for precision positioning in multi-axis systems. Features zero-backlash roller bearings and hardened guide shafts for smooth motion repeatability. Includes anti-rotation mechanism for torque resistance during vertical mounting.
Typical Applications:
- PCB component insertion machines
- Lens positioning in optical equipment
- Precision dispensing systems
- Automated test probe positioning
- Semiconductor wafer handling
Installation notes:
Lubricate guide shafts with ISO VG32 hydraulic oil before initial use.
Maximum side load capacity 15N. For vertical installations,
maintain ≤0.5mm/m alignment tolerance between guide rods and load.
Environmental Requirements:
- Air quality: ISO 8573-1 Class 3.4.2 (40μm filtration)
- Relative humidity: ≤85% (non-condensing)
- Vibration resistance: ≤4.9m/s² at 10-60Hz
| Property | Property Value |
|---|---|
| sku | HLQL12X100SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
