Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10S
$204.01
Regular price
$211.51
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X10S
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use torque-controlled tightening (0.7-1.2N·m for M4 screws).
Avoid side loads exceeding 15N. Perform 50-100 no-load cycles before full operation.
AirTAC HLQL12X10S Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X10S
- Type: Dual-axis guided precision pneumatic slide
- Bore size: 12mm
- Stroke: 10mm (±0.5mm adjustment range)
- Operating pressure: 0.05–0.7 MPa
- Accuracy grade: ±0.01mm/m (guide rail parallelism)
- Repeat positioning accuracy: ±0.005mm
- Guide structure: Linear ball bearings with 4-row configuration
- Piston rod material: Hard chrome-plated SUS420
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting style: Horizontal or vertical (axis downward)
- Port size: M5x0.8 (dual ports for air supply/exhaust)
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Body material: Anodized aluminum alloy (black oxide coating)
- Weight: 0.48kg (excluding mounting accessories)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H)
Ultra-compact dual-axis cylinder featuring cross-roller guidance for precision linear motion. Incorporates wear-resistant SKF/LG/LM guide blocks with 0.5μm surface roughness. Ideal for applications requiring micron-level stability with 0.003mm/m deflection under full load. Requires 5μm filtered dry air with ISO 8573-1:2010 class 3.4.3 air quality.
Typical Applications:
- Laser cutting head positioning systems
- Semiconductor wafer handling robots
- Optical lens alignment mechanisms
- High-speed pick-and-place sorting devices
- Precision dispensing equipment
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use torque-controlled tightening (0.7-1.2N·m for M4 screws).
Avoid side loads exceeding 15N. Perform 50-100 no-load cycles before full operation.
| Property | Property Value |
|---|---|
| sku | HLQL12X10S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
