Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SA
$229.60
Regular price
$237.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X10SA
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Operation tip:
Maintain 0.1-0.3mm lateral clearance during installation alignment.
Lubricate guide shafts monthly with ISO VG32 turbine oil. Avoid side
impact loads exceeding 2N during operation.
AirTAC HLQL12X10SA Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X10SA
- Type: Dual-axis guided slide cylinder (rodless type)
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting style: Horizontal base mount with M4 threaded holes
- Guide shafts: 2 chrome-plated steel rods Ø6mm
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, hardened steel slide block
- Seal material: Polyurethane (PU) seals
- Port size: M5x0.8 (dual ports at both ends)
- Weight: 0.65kg (excluding accessories)
- Dimensions: 98mm(L) × 32mm(W) × 24mm(H)
- Surface treatment: Anodized aluminum body, corrosion-resistant coating
- Load capacity: 3.5N radial / 7N axial (max dynamic)
High-precision dual-axis cylinder with integrated linear guide mechanism, designed for micron-level positioning tasks. Features zero leakage seals and wear-resistant slide surfaces, optimized for cleanroom-compatible operations. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 standards.
Typical Applications:
- Optical lens positioning in camera assembly lines
- PCB component insertion machines
- Precision dispensing systems for microelectronics
- Lab automation sample handling stages
- Semiconductor wafer inspection equipment
Operation tip:
Maintain 0.1-0.3mm lateral clearance during installation alignment.
Lubricate guide shafts monthly with ISO VG32 turbine oil. Avoid side
impact loads exceeding 2N during operation.
| Property | Property Value |
|---|---|
| sku | HLQL12X10SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
