Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAF
The AirTAC Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAF is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAF
The AirTAC HLQL12X10SAF is a symmetrical double-acting dual-rod slide-table cylinder that pairs an integrated ball-bearing linear guide with an air cylinder so the moving table travels straight with low deflection. The 12 mm bore at 10 mm stroke gives moderate thrust in a compact footprint, the dual rod doubles the output force, and the floating joint prevents side torque from reaching the rods. The ball-bearing guide is anti-rust and dust-proof, making it well suited to cleaner environments. An adjustable rubber stopper on the retraction side lets you fine-tune the end position on the return stroke.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing; CMSH, DMSH, and EMSH sensor switches fit the magnetic-switch slots on the body. Typical materials include an aluminium-alloy body and table, carbon-steel and stainless rods, NBR seals, a TPU bumper, and a sintered NdFeB magnet. We confirm the exact thrust, dimensions, and allowable load-moment values from the datasheet or on-page spec table on request.
Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAF Technical Specifications
| Model | Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SAF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQL (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 12 mm bore gives moderate thrust; step up to a larger bore if your application needs more push. Choose the ball-bearing HLQL guide when anti-rust and dust-proof operation are priorities, and the symmetrical HLQL body when you need mirrored port or mounting orientation about the center line. Stroke must fall within the bore-12 range listed in the datasheet. This version has a retract-side adjustable rubber stopper (AF); pick AS for an extension-side stopper, B for shock absorbers at both ends, or a blank code for basic bumper cushioning. Thread is PT; request G or NPT if your fittings differ. We route load, moment, and deflection sizing to the published tables and curves.
Applications
Pick-and-Place Head
Mounts a small gripper for precise part transfer between assembly stations with low deflection at the pick point.
Small-Parts Transfer
Moves lightweight components across a conveyor line with the anti-rust ball-bearing guide suited to clean environments.
Assembly Stage Stopper
Positions or gates a workpiece at an assembly station where straight guided travel and a cushioned stop are needed.
FAQ
What does the AF adjuster code mean on this HLQL model?
AF indicates an adjustable rubber stopper fitted on the retraction side only. The stopper lets you fine-tune the end position on the return stroke. For extension-side control choose AS, for shock absorbers at both ends choose B, and for basic bumper cushioning select the blank adjuster code.
What is the maximum operating pressure for this cylinder?
The maximum working pressure is 0.7 MPa (100 psi). For a 12 mm bore the operating range is 0.15 to 0.7 MPa (22 to 100 psi). Meter-out speed control should keep the travel speed within 50 to 500 mm/s. We confirm allowable load and moment values from the published datasheet tables.
