Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X10SBF
$237.72
Regular price
$245.22
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X10SBF
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Ensure guide rails are parallel within 0.05mm tolerance during mounting.
Use Class 7 tolerance pins for multi-unit alignment. Lubricate guide shafts
with ISO VG32 hydraulic oil before initial operation.
AirTAC HLQL12X10SBF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X10SBF
- Type: Dual-axis guided precision pneumatic slide cylinder
- Bore size: Ø12mm
- Stroke: 10mm (Standard options: 5-100mm)
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 15.2N at 0.6MPa
- Guide mechanism: Dual linear ball bearings
- Rod material: Hard chrome-plated steel
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU
- Temperature range: -20℃ to 80℃
- Weight: 1.2kg (with standard accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H)
- Mounting options: Horizontal/vertical/multi-stage stacking
- Accessory slots: T-slot & through-hole on base
- ISO compatibility: Compliant with ISO 15552 standards
High-rigidity dual-axis slide cylinder with integrated linear guides, delivering exceptional straightness (≤0.05mm/100mm) and minimal rotational play. Features corrosion-resistant construction and maintenance-free operation. Requires 5μm filtered air supply with oil mist lubrication recommended.
Industrial Applications:
- Precision alignment in semiconductor wafer handling
- Linear motion stages for optical inspection systems
- Automated liquid dispensing mechanisms
- PCB component insertion machines
- Medical device assembly automation
- High-speed sorting equipment guide rails
Installation note:
Ensure guide rails are parallel within 0.05mm tolerance during mounting.
Use Class 7 tolerance pins for multi-unit alignment. Lubricate guide shafts
with ISO VG32 hydraulic oil before initial operation.
Optional Accessories:
- Magnetic sensor kit (D-A93)
- Rod-end vibration dampers
- Heat-resistant seals (up to 120℃)
- Low-friction PTFE guide bushings
| Property | Property Value |
|---|---|
| sku | HLQL12X10SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
