Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X20SA
$235.65
Regular price
$243.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X20SA
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation guidelines:
Maintain parallelism within 0.05mm between guide rods during mounting.
Use flexible couplings when connecting to driven components.
For vertical installations, add 10-15% extra thrust capacity margin.
AirTAC HLQL12X20SA Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X20SA
- Type: Dual-axis guided slide cylinder (double rod)
- Bore size: Ø12mm
- Stroke: 20mm (standard), customizable up to 300mm
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Repeat positioning accuracy: ±0.01mm
- Cushioning: Adjustable rubber buffers at both ends
- Mounting style: Dual side/end mounting holes (M4×0.7)
- Material: Aluminum alloy body, hardened stainless steel guide rods
- Seal material: NBR + polyurethane
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Weight: 380g ±5% (without accessories)
- Dimensions: 100mm(L) × 42mm(W) × 32mm(H) (at full retraction)
High-rigidity dual-axis cylinder with linear ball bearing guides, engineered for precision linear motion requiring minimal deflection. Features anti-rotation design with dual 6mm ground shafts and dust-resistant wiper seals. Compatible with magnetic sensors (sensor slot included).
Typical Applications:
- PCB component insertion machines
- Laser marking equipment positioning stages
- Micro-dispensing systems in semiconductor manufacturing
- Optical inspection device XY tables
- Precision fixture alignment mechanisms
Installation guidelines:
Maintain parallelism within 0.05mm between guide rods during mounting.
Use flexible couplings when connecting to driven components.
For vertical installations, add 10-15% extra thrust capacity margin.
Optional Accessories:
HLQ-M12N1 magnetic sensor kit, HLQ-ADPT12 mounting brackets,
and HLQ-CV12 speed controller available separately.
| Property | Property Value |
|---|---|
| sku | HLQL12X20SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
