Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X20SAS
$226.34
Regular price
$233.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X20SAS
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Maintain parallelism within 0.1mm between mounting surfaces. For vertical installations,
use model HLQL12X20SAV variant with enhanced brake system. Relubricate every 500km of travel
using ISO VG32 hydraulic oil.
Load guidelines:
Maximum permissible moment: 1.2N·m (lateral), 2.4N·m (pitch/yaw).
Ensure load center aligns within ±2mm of shaft axis for optimal performance.
AirTAC HLQL12X20SAS Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X20SAS
- Type: Dual-axis guided slide cylinder (rectangular body)
- Bore size: 12mm
- Stroke: 20mm (±1mm tolerance)
- Shaft type: Hardened stainless steel dual shafts (Ø6mm)
- Guide length: 55mm
- Material: Aluminum alloy body, CRCA mounting brackets
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Repeat positioning accuracy: ±0.01mm
- Lubrication: Pre-lubricated (Grease retention structure)
- Mounting options: Through-hole M4×0.7 (front/rear flange)
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Protection rating: IP54 (standard seals)
- Max speed: 500mm/s (with cushioning)
- Weight: 0.68kg (including brackets)
- Dimensions: 106mm(L) × 34mm(W) × 34mm(H)
High-rigidity dual-axis cylinder with precision linear guide rails, featuring minimal deflection (<0.03mm at full load). Integrated scraper design prevents dust ingress, while PTFE-impregnated guide bushings ensure smooth motion. Compatible with vacuum applications when ordered with optional seals.
Typical Applications:
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling robots
- Medical device assembly with cleanroom requirements
- Laboratory sample positioning systems
- Optical fiber alignment mechanisms
Installation note:
Maintain parallelism within 0.1mm between mounting surfaces. For vertical installations,
use model HLQL12X20SAV variant with enhanced brake system. Relubricate every 500km of travel
using ISO VG32 hydraulic oil.
Load guidelines:
Maximum permissible moment: 1.2N·m (lateral), 2.4N·m (pitch/yaw).
Ensure load center aligns within ±2mm of shaft axis for optimal performance.
| Property | Property Value |
|---|---|
| sku | HLQL12X20SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
