Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X20SBF
$243.77
Regular price
$251.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X20SBF
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation notes:
Maintain 0.05mm maximum misalignment during mounting. Use flexible couplings when connecting to driven components. For vertical installations, add mechanical brake modules (sold separately). Lubricate guide rails every 500km of travel using ISO VG32 hydraulic oil.
AirTAC HLQL12X20SBF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X20SBF
- Type: Dual-axis guided precision slide cylinder
- Bore size: 12mm
- Stroke: 20mm (±1mm adjustable)
- Structure: Twin-rod with integrated linear guide
- Mounting: Side-mount & flange-mount compatibility
- Material: Aluminum alloy body (hard anodized), stainless steel rods
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Dual adjustable pneumatic cushions
- Lubrication: Pre-lubricated (non-replenishing design)
- Repeat accuracy: ±0.01mm
- Load capacity: 3.5N radial / 7N axial (dynamic)
- Weight: 0.62kg (excluding accessories)
- Dimensions: 120mm(L) × 40mm(W) × 60mm(H)
- Port size: M5x0.8 (dual ports for push/pull operation)
- ISO Standard: 15552 compliant
- Seal material: Polyurethane (NBR optional)
A high-precision linear motion solution combining pneumatic actuation with mechanical guidance. Features zero-backlash roller bearings and chromium-plated guide shafts for smooth operation. Ideal for applications requiring positional accuracy under variable loads. Includes built-in T-slot mounting channels for accessory integration.
Typical Applications:
- PCB component insertion machines
- Semiconductor wafer handling
- Automated optical inspection (AOI) systems
- Precision dispensing equipment
- Medical device assembly lines
- Robotic end-effector positioning
Installation notes:
Maintain 0.05mm maximum misalignment during mounting. Use flexible couplings when connecting to driven components. For vertical installations, add mechanical brake modules (sold separately). Lubricate guide rails every 500km of travel using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HLQL12X20SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
