Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SA
$241.44
Regular price
$248.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X30SA
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Apply light machine oil (ISO VG32 grade)
to guide shafts weekly in continuous operation. Avoid side-load connections exceeding 30% of
maximum capacity. Use C-shaped clamp mounting for vibration-heavy environments.
AirTAC HLQL12X30SA Dual-Axis Precision Slide Table Cylinder Specifications
- Model: HLQL12X30SA
- Type: Dual-axis guided rod cylinder with linear guide mechanism
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Shaft type: Hardened stainless steel dual shafts (chrome-plated)
- Operating pressure: 0.05–0.8 MPa
- Max speed: 500mm/s (with cushioning)
- Repeat positioning accuracy: ±0.02mm
- Max lateral load capacity: 8N
- Max moment load: 0.3N·m
- Cushioning: Adjustable rubber buffers at both ends
- Seal material: NBR + PU composite seals
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 pneumatic ports
- Weight: 0.65kg (without accessories)
- Dimensions: 135mm(L) × 42mm(W) × 35mm(H)
High-rigidity dual-axis cylinder featuring precision ground guide rails and ultra-low friction seals. The integrated linear guide system provides exceptional anti-rotation stability, with PTFE-coated sliding surfaces ensuring smooth motion. Includes mounting grooves on four sides for flexible installation. Requires 5μm filtered dry air supply.
Typical Applications:
- Precision positioning in SMT component placement machines
- Lens/fiber optic alignment systems
- Micro-dispensing equipment in PCB manufacturing
- Laboratory automation sample handling stages
- Semiconductor wafer inspection devices
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Apply light machine oil (ISO VG32 grade)
to guide shafts weekly in continuous operation. Avoid side-load connections exceeding 30% of
maximum capacity. Use C-shaped clamp mounting for vibration-heavy environments.
| Property | Property Value |
|---|---|
| sku | HLQL12X30SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
