Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAF
$226.34
Regular price
$233.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X30SAF
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Requires precise parallelism adjustment (≤0.05mm/m) between guide rails.
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Avoid side-load forces exceeding 15N. For vertical mounting, use locknut on piston rod.
AirTAC HLQL12X30SAF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X30SAF
- Type: Dual-axis guided cylinder with linear slide mechanism
- Bore size: 12mm
- Stroke: 30mm (standard), customizable up to 300mm
- Operating pressure: 0.1-0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffers at both ends
- Mounting style: Dual through-hole base mounting (M4 screw holes)
- Port size: M5x0.8 (Rc1/8 adaptor available)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Rod material: Stainless steel (SUS304) with hard chrome plating
- Body material: Anodized aluminum alloy
- Seal type: NBR wear-resistant seals
- Protection rating: IP54 (standard dust/water resistance)
- Weight: 0.85kg (including rail and carriage)
- Dimensions: 150mm(L) × 52mm(W) × 45mm(H) (at full retraction)
High-rigidity dual-axis pneumatic actuator combining cylinder and linear guide in one compact unit. Features precision ground shafts (HRC60+ hardness) and ball-bearing supported carriage for smooth motion. Integrated scraper seals prevent particulate ingress in guideways. Includes mounting slots for sensor brackets and adjustable stroke limiter.
Typical Applications:
- Precision alignment in semiconductor wafer handling
- Vertical Z-axis drives for CNC tool changers
- Optical component positioning systems
- Automated liquid dispensing equipment
- High-speed sorting mechanisms
Installation note:
Requires precise parallelism adjustment (≤0.05mm/m) between guide rails.
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Avoid side-load forces exceeding 15N. For vertical mounting, use locknut on piston rod.
| Property | Property Value |
|---|---|
| sku | HLQL12X30SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
