Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAS
The AirTAC Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAS is a genuine HLQ slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a ball-bearing guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guideball-bearing guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAS
The AirTAC HLQL12X30SAS is a symmetrical ball-bearing guided slide-table cylinder with a 12 mm bore and 30 mm stroke. The dual-rod, double-acting design integrates an air cylinder with a linear ball-bearing guide so the table travels straight with low deflection. A floating joint protects the rods from side torque, and the dual rod layout provides higher thrust than a single-rod unit of the same bore. The HLQL ball-bearing guide is anti-rust and dust-proof, making it suitable for environments where cross-roller guides may be less appropriate.
This is a genuine AirTAC part with a standard magnet fitted for position sensing. Compatible sensor switches include CMSH, DMSH, and EMSH series, which mount in the magnetic-switch slots on the cylinder body. We confirm exact thrust values, dimensions, and allowable load/moment data from the AirTAC datasheet or on-page spec table on request.
Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAS Technical Specifications
| Model | Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SAS |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLQL (ball-bearing guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
A 12 mm bore gives moderate thrust in a compact footprint; choose a larger bore if your application needs more push force. The HLQL ball-bearing sub-family suits applications needing anti-rust, dust-proof guided travel. Stroke 30 mm must fall within the bore 12 stroke range listed in the datasheet. The AS adjuster on this model provides an adjustable rubber stopper on the extension side only; pair it with the appropriate thread option for your fittings. Allowable load and moment capacities are published as tables and deflection curves - contact us to confirm sizing for your workload.
Applications
Pick-and-Place Head
Mounts a gripper for precise part pickup and placement where the ball-bearing guide keeps travel straight and dust-resistant over repeated cycles.
Small-Parts Transfer
Shifts small components between conveyor lanes or stations with guided linear motion and symmetrical mounting for balanced installations.
Assembly Stage Stop
Positions or stops a workpiece at an assembly station using the extension-side rubber stopper for repeatable end-of-stroke positioning.
FAQ
What does the AS adjuster code mean on the HLQL12X30SAS?
AS indicates an adjustable rubber stopper fitted on the extension side only. The retraction side uses the standard bumper cushion. This is one of several adjuster options available on the HLQ/HLQL series; others include B for shock absorbers on both ends or AF for a rubber stopper on the retraction side.
What is the maximum operating pressure for this cylinder?
The maximum working pressure is 0.7 MPa (100 psi). For the 12 mm bore, the operating range is 0.15-0.7 MPa (22-100 psi). Never exceed 0.7 MPa; proof pressure is 1.2 MPa for qualification testing only.
