Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SB
$287.97
Regular price
$295.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X30SB
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Requires precise parallelism adjustment (≤0.05mm/m) between guide rails. Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation. For vertical installations, use supplemental support brackets when payload exceeds 2kg.
AirTAC HLQL12X30SB Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X30SB
- Type: Dual-axis slide cylinder with guide mechanism
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable buffer (both ends)
- Mounting style: Base mounting with precision alignment grooves
- Port size: M5x0.8 (standard), G1/8 optional
- Piston rod material: Hard chrome-plated SUS304
- Seal material: Polyurethane (PU) + NBR combination
- Temperature range: -10℃ to 80℃
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Protection rating: IP54 (standard), IP67 optional
- Weight: 0.35kg (without accessories)
- Dimensions: 132mm(L) × 34mm(W) × 34mm(H)
High-rigidity dual-axis cylinder featuring integrated linear guides and precision ground shafts. The hardened stainless steel construction ensures minimal deflection (≤0.03mm at full load) and wear resistance. Includes anti-rotation mechanism for stable linear motion, with optional magnetic piston for position feedback.
Typical Applications:
- Precision alignment in semiconductor handling systems
- Vertical Z-axis movement in 3D measuring machines
- Component insertion mechanisms in PCB assembly
- Optical lens positioning systems
- Automated test equipment (ATE) fixture actuation
Installation note:
Requires precise parallelism adjustment (≤0.05mm/m) between guide rails. Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation. For vertical installations, use supplemental support brackets when payload exceeds 2kg.
Performance Features:
- Dual preloaded linear ball bearings for zero backlash
- 4 mounting slots (M4 thread) for flexible configuration
- Low-friction seals with ≤0.15N starting pressure
- Anodized aluminum body with corrosion resistance
| Property | Property Value |
|---|---|
| sku | HLQL12X30SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
