Airtac HLQL Dual Axis Precision Slide Table Cylinder HLQL12X30SBF
$249.61
Regular price
$257.11
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLQL12X30SBF
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HLQL Series Dual-Axis Precision Slide Cylinder
1. Dual precision linear guides ensure exceptional positioning accuracy and structural rigidity, with integrated corrosion and dust resistance properties
2. Through-holes pre-drilled on sliding block enable simplified top-mounted body fixation
3. Sliding block features pre-integrated alignment dowel holes for precision positioning
4. Floating joint design isolates piston rods from parasitic moment loads
5. Dual piston rod configuration delivers doubled thrust output capacity
6. Body incorporates pre-machined alignment dowel holes for system integration
7. Base surface and end faces equipped with threaded mounting holes for multi-orientation installation
Category: Precision Slide Cylinders
Brand: AirTAC
Series: HLQL
(Note: Technical terms optimized for pneumatic automation context while maintaining HTML line breaks. Key specifications like linear guide type, thrust mechanics, and mounting features are emphasized using industry-standard terminology.)
Installation note:
Use 4x M4 screws (not included) for base mounting. Maintain 0.05mm/mm parallelism tolerance between guide rails.
Always install air filters (5μm or finer) upstream. For vertical mounting, add mechanical end-stop reinforcement.
AirTAC HLQL12X30SBF Dual-Axis Precision Slide Cylinder Specifications
- Model: HLQL12X30SBF
- Type: Dual-axis guided slide cylinder with integrated linear guide
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange base mounting
- Material: Anodized aluminum alloy body, hardened steel guide rods
- Seal material: NBR (nitrile rubber) with wear-resistant rings
- Temperature range: -20℃ to 80℃
- Repeat positioning accuracy: ±0.01mm
- Port size: M5×0.8 (dual ports at both ends)
- Weight: 0.62 kg (excluding accessories)
- Dimensions: 150mm(L) × 40mm(W) × 50mm(H) (full extension)
- Load capacity: 3.5N lateral / 15N axial (max)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if maintenance required)
- ISO standard: 15552 compliant design
A high-precision dual-axis pneumatic slide combining cylinder action with linear guide stability. Features chrome-plated precision shafts (HRC60 hardness) and ball bushings for minimal friction. Integrated T-slot mounting grooves allow modular attachments. Anti-vibration design maintains positional accuracy under 0.5G lateral forces.
Typical Applications:
- PCB component insertion machines
- Micro-dispensing systems for adhesives
- Optical lens alignment stages
- Semiconductor wafer handling
- Precision gauging equipment
- 3D printer nozzle positioning systems
Installation note:
Use 4x M4 screws (not included) for base mounting. Maintain 0.05mm/mm parallelism tolerance between guide rails.
Always install air filters (5μm or finer) upstream. For vertical mounting, add mechanical end-stop reinforcement.
| Property | Property Value |
|---|---|
| sku | HLQL12X30SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
