Airtac HLS Precision Slide Cylinder HLS12X100S
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X100S Precision Slide Cylinder Specifications
- Model: HLS12X100S
- Type: Guided rod-type slide cylinder with linear bearings
- Bore size: 12mm
- Stroke: 100mm (standard), customizable up to 300mm
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 25N at 0.5MPa
- Piston speed: 50–800mm/s
- Repeat positioning accuracy: ±0.02mm
- Max lateral load: 2.5N·m
- Mounting type: Horizontal/Vertical (dual orientation)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Weight: 0.68kg (without accessories)
- Dimensions: 170mm(L) × 35mm(W) × 35mm(H) (stroke extended)
- Port size: M5x0.8 (standard), G1/8 optional
- Built-in sensors: Magnetic switch groove (M9 connector compatible)
High-rigidity linear motion solution combining cylinder and guide mechanism. Features low-friction movement with adjustable cushioning and embedded lubrication units. Anti-rotation design maintains orientation stability during 100,000+ cycle operations. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Precision alignment in semiconductor wafer handling
- Linear positioning for laser marking systems
- PCB component insertion mechanisms
- Micro-dispensing equipment in medical device assembly
- Optical lens positioning stages
Installation note:
Ensure guide rail parallelism within 0.05mm/m during mounting.
Use torque wrench (0.5-0.7N·m) for mounting bolts to prevent rail deformation.
Lubricate every 3 months under normal operation.
| Property | Property Value |
|---|---|
| sku | HLS12X100S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
