Airtac HLS Precision Slide Cylinder HLS12X100SA
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X100SA Precision Slide Table Cylinder Specifications
- Model: HLS12X100SA
- Type: Guided precision slide cylinder (double-shaft type)
- Bore size: 12mm
- Stroke: 100mm ±0.5mm
- Operating pressure: 0.1–0.7 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Repeat positioning accuracy: ±0.01mm
- Max. thrust: 24N at 0.5MPa
- Max. speed: 500mm/s
- Mounting style: Square flange (MF1) with 4xM3 threaded holes
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy cylinder tube, SUS304 piston rod
- Surface treatment: Hard anodized (cylinder), chrome-plated (rod)
- Protection rating: IP54
- Weight: 0.48kg
- Dimensions: 182mm(L) × 42mm(W) × 42mm(H)
High-rigidity linear motion solution with precision ground guide rails and low-friction brass bushing. Features dual-shaft stabilization for minimal lateral play (±0.03mm) and integrated T-slot mounting grooves. Requires filtered air (5μm+), with optional magnetic sensor slots (model: HLS12X100SA-M) for position feedback.
- Semiconductor wafer handling robots
- Micro-dispensing systems in PCB assembly
- Optical lens positioning stages
- Laboratory automation slide mechanisms
- 3D printer Z-axis calibration devices
- Medical analyzer reagent arm control
Installation notes:
Maintain 0.02mm/m alignment tolerance during mounting. Lubricate with ISO VG32 turbine oil
every 50km of travel. Avoid side loads exceeding 3N·m. For vertical installations,
use counterbalance valves (sold separately).
| Property | Property Value |
|---|---|
| sku | HLS12X100SA |
| External Stop Block Type | Stroke Adjustment Screws at Both Ends |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
