Airtac HLS Precision Slide Cylinder HLS12X100SAF
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X100SAF Precision Slide Table Cylinder Specifications
- Model: HLS12X100SAF
- Series: HLS Type Linear Guide Cylinder
- Bore size: Ø12mm
- Stroke: 100mm (customizable 10-300mm)
- Operating pressure: 0.1-0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Linear guide integrated structure
- Repeat positioning accuracy: ±0.02mm
- Max speed: 500mm/s
- Seal material: NBR + Special polyurethane
- Port size: M5x0.8
- Weight: 0.82kg (bare cylinder), 1.15kg (with guide)
- Dimensions: 300mm(L) × 34mm(W) × 50mm(H)
(Base length 200mm + stroke 100mm) - Guide rail hardness: HRC58-62
- Surface treatment: Black anodized main body
High-precision linear motion solution combining pneumatic cylinder and linear guide in monoblock design. Features zero-backlash rolling contact bearings and chrome-plated piston rod (HRC45+ hardness). Includes magnetic piston for position sensing compatibility. Optimized for minimal stick-slip effect during low-speed operation.
- Precision component assembly stations
- Lens polishing equipment positioning
- PCB board testing fixtures
- Pharmaceutical blister packaging machines
- Semiconductor wafer handling systems
Operation note:
Requires 5μm filtered lubricated air (ISO8573-1 class 4). Lubricate guide rails with
ISO VG32 turbine oil monthly. Avoid lateral forces exceeding 15N during mounting.
| Property | Property Value |
|---|---|
| sku | HLS12X100SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
