Airtac HLS Precision Slide Cylinder HLS12X100SAS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X100SAS Precision Slide Cylinder Specifications
- Model: HLS12X100SAS
- Series: HLS (High-Precision Linear Slide Series)
- Bore size: Ø12mm
- Stroke: 100mm (adjustable stroke available)
- Operating pressure: 0.05-0.7 MPa
- Piston speed: 50-700 mm/s
- Mounting type: Dual linear guide rails
- Guide rail length: 180mm
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 35N (at 0.5MPa)
- Air port size: M5x0.8
- Seal material: Polyurethane (PU) + special wear ring
- Temperature range: -10℃ to 80℃
- Weight: 380g ±2%
- Dimensions: 190mm(L) × 34mm(W) × 34mm(H)
- Accessories: Built-in magnetic sensor slot (SAS suffix indicates sensor-ready)
Ultra-compact slide cylinder with integrated linear guides, engineered for micron-level precision in automated systems. Features chromium-plated piston rod and anodized aluminum body for corrosion resistance. The dual rail structure provides 4-directional load capacity up to 12N·m, with optional grease nipple for long-term maintenance.
- PCB component insertion machines
- Lens coating equipment positioning stages
- Medical device assembly automation
- 3C product testing fixtures
- Precision dispensing systems
Installation guidelines:
Maintain parallelism within 0.05mm/m during mounting. Use M4x8 mounting screws with 0.7-0.9Nm torque.
Lubricate with ISO VG32 turbine oil before initial operation. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | HLS12X100SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
