Airtac HLS Precision Slide Cylinder HLS12X100SB
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X100SB Precision Slide Table Cylinder Specifications
- Model: HLS12X100SB
- Series: HLS (High-Precision Linear Slide)
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Structure type: Single-axis slide with integrated linear guide
- Mounting style: Horizontal/Vertical multi-position
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Adjustable elastic buffer (both ends)
- Repeat positioning accuracy: ±0.01mm
- Lubrication method: Oil mist lubrication required
- Material: Aluminum alloy body (A6063-T5), Stainless steel piston rod (SUS304)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Load capacity: 15N (dynamic), 45N (static)
- Max speed: 50–1000 mm/s
- Port size: M5x0.8 (G1/8 adapter optional)
- Weight: 0.82kg (excluding accessories)
- Dimensions: 200mm(L) × 30mm(W) × 34mm(H) (full extension)
- Protection rating: IP40 (dust protected)
High-rigidity slide cylinder combining pneumatic actuation with precision linear guidance, featuring T-slot mounting surfaces for modular assembly. The hardened steel guide rails and four-row ball bearing system achieve ≤0.005mm/100mm straightness. Requires 5μm filtered air and ISO VG32 hydraulic oil for lubrication.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling systems
- Pharmaceutical blister packaging alignment
- Micro-dispensing robot arms
Installation guidance:
Maintain 0.02mm/m alignment tolerance during mounting. Use torque-controlled fasteners (0.49–0.69N·m for M4 screws).
Perform 50 low-pressure break-in cycles (<0.1MPa) before full operation.
| Property | Property Value |
|---|---|
| sku | HLS12X100SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
