Airtac HLS Precision Slide Cylinder HLS12X100SBF
The AirTAC Airtac HLS Precision Slide Cylinder HLS12X100SBF is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLS Precision Slide Cylinder HLS12X100SBF
The AirTAC HLS12X100SBF is a double-acting dual-rod slide-table cylinder with an integrated cross-roller linear guide for straight, low-deflection table travel. The 12 mm bore and 100 mm stroke give moderate thrust through two rods while the floating joint prevents side torque on the rods. This variant fits a shock absorber on the retraction side only, cushioning the return stroke where the impact is highest.
This is a genuine AirTAC part with a standard magnet for position sensing; CMSH, DMSH and EMSH series switches mount in the body slots. We provide the exact thrust, dimensions, load and moment ratings from the published datasheet or on-page table on request.
Airtac HLS Precision Slide Cylinder HLS12X100SBF Technical Specifications
| Model | Airtac HLS Precision Slide Cylinder HLS12X100SBF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLS (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 balances moderate thrust against a compact body within the HLS cross-roller family; a bigger bore gives more push, a smaller bore is lighter for fine gripper work. Stroke 100 mm is available within the bore 12 range - consult the datasheet table for the full list. Adjuster BF places the shock absorber on the retraction side, ideal when the return stroke carries the heavier or faster-moving load; choose B for both ends, AF for rubber stopper retraction side, or blank for the basic bumper. Thread is PT; G and NPT are available on request. We confirm load, moment and deflection from the published tables and curves - share your application for sizing help.
Applications
Gripper Traverse
A 12 mm bore cross-roller slide moves a gripper cleanly through 100 mm with low table deflection at the work face.
Return-Stroke Transfer
Shock absorber on the retraction side cushions the heavier return of a parts shuttle for smooth, repeatable cycling.
Assembly Positioning
Dual-rod straight-line travel positions a subassembly fixture accurately across a 100 mm working stroke.
FAQ
What does the BF adjuster mean on HLS12X100SBF?
BF means a shock absorber on the retraction side only. This is chosen when the return stroke has the higher impact or speed and the extension side can use the standard bumper. B (both ends) is the alternative when both directions need cushioning.
Is the magnet optional on this slide table?
No. The S in the model code means a magnet is standard and fitted to every unit; it is not an option to decline. Compatible position sensors are the CMSH, DMSH and EMSH series mounted in the body slots.
