Airtac HLS Precision Slide Cylinder HLS12X100SBS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS Precision Slide Cylinder HLS12X100SBC Technical Details
- Model: HLS12X100SBC
- Series: HLS (High Precision Linear Slide Series)
- Stroke: 100mm
- Bore size: Φ12mm
- Action type: Double acting
- Guide type: Linear ball bearing guide
- Repeat accuracy: ±0.01mm
- Max. speed: 1.5m/s
- Operating pressure: 0.05-0.7MPa
- Temperature range: -20℃ to 80℃
- Buffer type: Elastic buffer + external hydraulic absorber
- Lubrication: Pre-lubricated (Maintenance-free for 2,000km travel)
- Mounting style: Horizontal/vertical base mounting
- Material: Aluminum alloy body, stainless steel rod
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Weight: 680g ±2%
- Dimensions: 180mm(L) × 42mm(W) × 42mm(H)
- Seal material: PU/NBR compound seals
- Load capacity: 15N radial / 30N axial (dynamic)
High-rigidity linear actuator combining pneumatic cylinder and precision guide mechanism. Features chromium-plated piston rod with wear-resistant treatment, integrated guide rail with adjustable preload, and optional magnetic sensor slots. Ideal for applications requiring smooth motion profile and micron-level positioning stability.
- PCB component insertion machines
- Lens coating equipment positioning stages
- Medical device assembly automation
- Precision inspection jig actuation
- Semiconductor wafer handling systems
Installation note:
Apply anti-vibration pads under mounting base when used in high-frequency (>5Hz) cycles.
Relubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HLS12X100SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
