Airtac HLS Precision Slide Cylinder HLS12X10S
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X10S Precision Slide Table Cylinder Specifications
- Model: HLS12X10S
- Type: Compact guided rodless cylinder with linear guide rail
- Bore size: Ø12mm
- Stroke: 10mm (Standard strokes: 10-300mm available)
- Operating pressure: 0.1-0.7 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 14.7N at 0.5MPa
- Guide rail type: Dual-axis precision linear guide
- Rail length: 58mm (for 10mm stroke model)
- Material: Aluminum alloy body, hardened steel guide rods
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Maintenance-free for 2000km travel)
- Weight: 0.28kg (excluding accessories)
- Dimensions: 58mm(L) × 34mm(W) × 28mm(H)
- Mounting: 2x M3 threaded holes on base
- Accessory ready: Compatible with AT-φ4/φ6 speed controllers
Ultra-compact slide cylinder combining pneumatic actuation with precision linear guidance. Features dual-axis roller bearings for smooth motion and minimal stick-slip effect. The hardened guide rails provide 0.5μm RA surface roughness for high positional repeatability. Integrated T-slot design allows direct mounting of tooling plates.
- Micro-part positioning in semiconductor test handlers
- Optical lens alignment mechanisms
- PCB inspection probe drives
- Medical device assembly stations
- 3C product automated screwdriving units
- Laser marking machine XY stages
Installation note:
Ensure guide rail parallelism within 0.05mm/m during mounting. Use only M3 screws
with 0.5N·m torque limit to prevent base deformation. Lubricate guide rods with
ISO VG32 hydraulic oil if operated in high-cycledust environments.
| Property | Property Value |
|---|---|
| sku | HLS12X10S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
