Airtac HLS Precision Slide Cylinder HLS12X10SA
The AirTAC Airtac HLS Precision Slide Cylinder HLS12X10SA is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLS Precision Slide Cylinder HLS12X10SA
The AirTAC HLS12X10SA is a double-acting dual-rod slide-table cylinder with an integrated cross-roller linear guide. At 12mm bore and 10mm stroke, it delivers moderate thrust for guided motion, while the cross-roller guide provides high rigidity and low deflection. Adjustable rubber stoppers on both ends allow fine-tuning of the end-of-stroke cushioning, and a floating joint protects the rods from side torque.
This is a genuine AirTAC part with a standard magnet for position sensing. Compatible sensor switches include CMSH, DMSH, and EMSH series. We confirm exact thrust, dimensions, and allowable load/moment values from the AirTAC datasheet or on-page specification table on request.
Airtac HLS Precision Slide Cylinder HLS12X10SA Technical Specifications
| Model | Airtac HLS Precision Slide Cylinder HLS12X10SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLS (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
For light to moderate thrust, the 12mm bore balances force and compactness; step up to a larger bore for more push. The HLS cross-roller guide maximizes rigidity and precision; consider HLQ for anti-rust or dust-proof needs. This model includes adjustable rubber stoppers at both ends for end-position cushioning control. Choose the basic version if standard bumpers suffice, or a B-type shock-absorber option for higher energy absorption on this bore. Select stroke from the bore's valid stroke table. Contact us to confirm load and moment capacity from published AirTAC tables and deflection curves.
Applications
Small-Parts Transfer
Adjustable rubber stoppers at both ends cushion the transfer of small parts between conveyor stations with precise 10mm guided travel.
Probe Positioning Stage
Cross-roller rigidity and adjustable end stops position a test probe repeatably against a workpiece without lateral drift.
Adjustable End Stop
Fine-tune both end positions with rubber stoppers on each side, ideal for applications needing precise travel limits within a short stroke.
FAQ
What does the A in HLS12X10SA mean?
The A suffix indicates adjustable rubber stoppers on both ends, letting you fine-tune end-of-stroke cushioning. The basic HLS12X10S has standard bumpers without adjustment. Other options include AF (adjustable stopper, retraction side only), AS (extension side only), and B-type shock absorbers for higher energy dissipation.
What load and moment can the HLS12X10SA handle?
Maximum working pressure is 0.7 MPa (100 psi) with an operating range of 0.15 to 0.7 MPa for the 12mm bore. Allowable load, moment, and kinetic energy are published as tables and deflection curves in the AirTAC datasheet. Contact us and we will confirm the exact values for your application.
