Airtac HLS Precision Slide Cylinder HLS12X10SAF
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X10SAF Precision Slide Table Cylinder Specifications
- Model: HLS12X10SAF
- Type: Dual-axis guided precision cylinder with linear slide
- Bore size: Ø12mm
- Stroke: 10mm (Standard), customizable up to 500mm
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 48N at 0.5MPa
- Piston speed: 50–800mm/s
- Repeat accuracy: ±0.01mm
- Guide rail type: Dual linear ball bearings
- Rod material: Hardened stainless steel (SUS420J2)
- Seal material: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Weight: 580g ±2% (excluding accessories)
- Dimensions:
- Body length: 82mm
- Total width: 42mm
- Height (including rail): 34mm
- Mounting hole spacing: 30mm × 30mm
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 2,000km travel)
Ultra-compact slide cylinder combining pneumatic actuation with precision linear guidance, featuring zero-backlash ball bearing slides and hardened ground shafts. The anodized aluminum body ensures corrosion resistance while maintaining minimal weight. Designed for applications requiring both thrust and positional accuracy in confined spaces.
- Micro-assembly in semiconductor wafer handling
- Precision dispensing systems for adhesives
- Lens positioning in optical inspection equipment
- High-speed pick-and-place for SMD components
- Automated test probe positioning systems
Installation tip:
Use M3×0.5 mounting screws with 0.4-0.6N·m torque. For vertical installations,
maintain weekly lubrication intervals using ISO VG32 turbine oil. Avoid side
load exceeding 15N to preserve guide accuracy.
- ±0.005mm/50mm straightness accuracy
- 10μm resolution with optional encoder feedback
- Vibration damping rubber pads integrated at both ends
- Compatible with vacuum pick-up attachments
| Property | Property Value |
|---|---|
| sku | HLS12X10SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
