Airtac HLS Precision Slide Cylinder HLS12X10SAS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X10SAS Precision Slide Table Cylinder Specifications
- Model: HLS12X10SAS
- Series: HLS (High-Precision Linear Slide Series)
- Bore size: 12mm
- Stroke: 10mm (customizable up to 500mm)
- Operating pressure: 0.1-0.9 MPa
- Maximum thrust: 16.3N at 0.5MPa
- Repeat positioning accuracy: ±0.01mm
- Table width: 24mm
- Guide type: Dual linear ball bearings
- Piston rod material: Stainless steel SUS304
- Body material: Hard-anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Weight: 240g ±5g
- Dimensions: 102mm(L) × 30mm(W) × 24mm(H)
- Mounting options: 3x M3 threaded holes (bottom/side)
- Sensor compatibility: Built-in magnet for proximity switches
- Protection rating: IP54 (Dust protected & water splashed)
Ultra-compact linear motion solution combining pneumatic cylinder and precision guide mechanism. Features zero-backlash ball bearing guides with 4-row raceway structure for smooth motion and high moment resistance. Integrated T-slot design allows direct mounting of tools/workpieces. Optimized air circuit ensures stable low-speed movement (≥30mm/s).
- PCB component insertion machines
- Micro-dispensing systems for adhesives
- Optical lens alignment stations
- Semiconductor wafer handling
- Precision gauging equipment
- Laboratory automation sample positioning
Operational note:
For optimal performance, maintain air quality at ISO 8573-1:2010 Class 2-4-2
(max 5mg/m³ oil content). Use 50μm filter regulator. Avoid lateral impact forces
exceeding 3N·m. Lubricate guide rails every 500km travel distance with
ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HLS12X10SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
