Airtac HLS Precision Slide Cylinder HLS12X10SB
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X10SB Precision Slide Table Cylinder Specifications
- Model: HLS12X10SB
- Series: HLS Precision Linear Slide Series
- Bore size: 12mm
- Stroke: 10mm (customizable up to 300mm)
- Operating pressure: 0.05-0.7 MPa
- Max speed: 500 mm/s
- Structure: Twin shaft with linear guide
- Material: Aluminum alloy body, stainless steel rod
- Seal type: NBR/PU seals
- Repeat positioning accuracy: ±0.01mm
- Load capacity: 15N (lateral), 30N (axial)
- Cushioning: Adjustable air cushion
- Mounting options: Side mounting holes + base flange
- Sensor slots: Standard magnetic switch groove
- Temperature range: -20℃ to 80℃
- Weight: 0.28kg (with 10mm stroke)
- Dimensions: 110mm(L) × 32mm(W) × 24mm(H)
Ultra-compact slide cylinder integrating cylinder piston and linear guide rail, designed for micron-level precision positioning. Features dual-shaft anti-rotation design with hardened steel guide rods and preloaded ball bearings. The anodized body provides corrosion resistance in Class 4 cleanliness environments. Includes built-in adjustable stoppers for stroke limitation.
- PCB component insertion machines
- Lens coating automation systems
- Semiconductor wafer handling
- Precision dispensing equipment
- Medical analyzer slide mechanisms
- 3D printer Z-axis positioning
Installation notes:
Requires 0.01mm/m alignment accuracy during mounting. Use M3x0.5 mounting screws (6Nm max torque).
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation. For vertical installations,
add 20% safety factor to load calculations.
| Property | Property Value |
|---|---|
| sku | HLS12X10SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
