Airtac HLS Precision Slide Cylinder HLS12X10SBF
The AirTAC Airtac HLS Precision Slide Cylinder HLS12X10SBF is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLS Precision Slide Cylinder HLS12X10SBF
The HLS12X10SBF is a double-acting dual-rod slide table cylinder with an integrated cross-roller guide. A 12mm bore and 10mm stroke deliver moderate thrust while the cross-roller guide ensures high rigidity and low deflection. The floating joint spares the rods from side torque, and the dual rod doubles the thrust.
This is a genuine AirTAC part with a standard magnet for sensor switches (CMSH/DMSH/EMSH). The BF adjuster adds a shock absorber on the retraction side. We confirm thrust, dimensions, and load-moment from the datasheet or on-page table on request.
Airtac HLS Precision Slide Cylinder HLS12X10SBF Technical Specifications
| Model | Airtac HLS Precision Slide Cylinder HLS12X10SBF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLS (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Selecting a larger bore provides more push, while the 10mm stroke stays within the bore's table. The cross-roller guide (HLS) provides high precision and rigidity. The BF adjuster adds a shock absorber on the retraction side for smoother cushioning. The thread is PT. Route load and moment sizing to us, as they are published as tables and curves.
Applications
Pick-and-Place
Precise cross-roller guided travel for mounting small grippers in electronic assembly pick-and-place operations.
Parts Transfer
Moves small components accurately across conveyor stations with moderate thrust and minimal deflection.
Assembly Stage
Provides a rigid, low-deflection platform for aligning and pressing small parts in automated assembly stages.
FAQ
What does the BF adjuster code mean?
The BF code indicates a shock absorber is installed on the retraction side for smoother end-of-stroke cushioning.
Is the magnet optional on this slide table?
No, the magnet is standard on the entire HLS line and cannot be declined. It is used with CMSH/DMSH/EMSH sensors.
