Airtac HLS Precision Slide Cylinder HLS12X10SBS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X10SBS Precision Slide Table Cylinder Technical Details
- Model: HLS12X10SBS
- Type: Guided rodless cylinder with integrated linear guide
- Bore size: Ø12mm
- Stroke: 10mm (Customizable: 5-300mm)
- Operating pressure: 0.05-0.7 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber buffers at both ends
- Guide type: Dual linear ball bearings
- Repeat positioning accuracy: ±0.01mm
- Mounting: Standard M4 threaded holes (4x)
- Material: Aluminum alloy body, hardened steel guide rods
- Port size: M5x0.8 (dual ports for forward/return)
- Weight: 0.38kg (excluding accessories)
- Dimensions: 56mm(W) × 42mm(H) × 72mm(L) (at full retraction)
- Lubrication: Pre-lubricated (Grease-free operation)
- Max lateral load: 3.5N
- Max moment load: 0.3N·m
- IP rating: IP54 (Dust protected & water splashed)
Ultra-compact guided actuator combining pneumatic cylinder and linear guide rail, delivering micron-level positioning accuracy. Features anti-rotation design with zero mechanical play, optimized for high-speed reciprocation (up to 1.5m/s). Integrated T-slot allows direct mounting of sensors or tooling plates. Compatible with vacuum applications when equipped with optional seals.
- PCB component insertion machines
- Semiconductor wafer handling
- Micro-dispensing systems
- Optical lens alignment stages
- Laboratory automation (pipette arms, sample handlers)
- Medical device assembly (syringe plunger actuation)
Operation tip:
Maintain air filtration at 15μm or finer. For vertical installations,
reduce payload to 60% of maximum rating. Use 0.3-0.5MPa pressure
for optimal speed/accuracy balance. Perform monthly rail lubrication
with ISO VG32 equivalent grease.
| Property | Property Value |
|---|---|
| sku | HLS12X10SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
