Airtac HLS Precision Slide Cylinder HLS12X20SAF
$200.76
Regular price
$208.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLS12X20SAF
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated cross roller guide and cylinder design ensures high-strength, high-precision operation with exceptional load capacity, featuring superior linearity and anti-rotation accuracy for precision assembly applications;
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
Installation tips:
Use Class 4 mounting surface flatness (≤0.01mm) for optimal performance.
Align cylinder axis within 0.05° of applied load direction. For vertical
installations, consider adding a counterbalance valve. Lubricate guide rails
every 500km of travel using ISO VG32 turbine oil.
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X20SAF Precision Slide Table Cylinder Specifications
- Model: HLS12X20SAF
- Type: Double-acting guided cylinder with integrated slide table
- Bore size: 12mm
- Stroke: 20mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Side-mounted base with 25mm spaced M4 threaded holes
- Guide mechanism: Dual linear ball bearings (preloaded)
- Repeat positioning accuracy: ±0.01mm
- Operating temperature: -10℃ to 70℃
- Material: Aluminum alloy body, hardened stainless steel rod
- Seal material: Polyurethane (NBR optional)
- Port size: M5x0.8 (Rc1/8 adaptor included)
- Lubrication: Pre-lubricated (Oil-free operation possible with special seals)
- Weight: 0.45kg (including mounting hardware)
- Dimensions: 120mm(L) × 30mm(W) × 30mm(H) (at mid-stroke position)
- Protection rating: IP40 (IP67 with optional wiper seals)
- Certification: RoHS compliant
A high-precision linear motion solution combining pneumatic actuation with mechanical guidance. Features zero-backlash ball bearing guides and hardened ground shafts for smooth operation. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight properties. Integrated T-slot on slide table allows modular tooling attachment.
Typical Applications:
- Precision alignment stages in semiconductor wafer handling
- Linear indexing in automated test equipment
- Optical component positioning systems
- Micro-dispensing mechanisms for adhesive applications
- Laboratory automation requiring vibration-free movement
Installation tips:
Use Class 4 mounting surface flatness (≤0.01mm) for optimal performance.
Align cylinder axis within 0.05° of applied load direction. For vertical
installations, consider adding a counterbalance valve. Lubricate guide rails
every 500km of travel using ISO VG32 turbine oil.
Critical Notes:
- Maximum side load capacity: 15N (horizontal), 10N (vertical)
- Avoid rapid pressure changes >0.5 MPa/sec to prevent seal damage
- Use clean dry air with 5-40μm filtration (ISO 8573-1:2010 Class 3.4.2)
| Property | Property Value |
|---|---|
| sku | HLS12X20SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
