Airtac HLS Precision Slide Cylinder HLS12X20SAS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X20SAS Precision Linear Slide Cylinder Specifications
- Model: HLS12X20SAS
- Type: Guided precision slide cylinder with integrated linear guide
- Bore size: 12mm
- Stroke: 20mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 12.5N at 0.5MPa
- Piston speed: 50–800 mm/s
- Repeat positioning accuracy: ±0.01mm
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Horizontal/vertical (dual orientation)
- Guide rail type: High-rigidity ball bearing structure
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR with wear-resistant coating
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
- Port size: M5x0.8 (dual ports for forward/return stroke)
- Weight: 0.62kg (excluding accessories)
- Dimensions: 120mm(L) × 40mm(W) × 40mm(H) (full extension)
- Accessory options: Magnetic sensor slot (D-M9N compatible)
The HLS12X20SAS combines pneumatic actuation with precision linear guidance, featuring zero backlash and minimal stick-slip effect. Its dual-axis rail design eliminates rotational movement, achieving 0.02mm/m straightness accuracy. The hardened guide rails withstand 2.5kN radial loads, making it ideal for applications requiring both force transmission and positional precision.
- Semiconductor wafer handling robots
- Laser cutting head positioning systems
- Automated optical inspection (AOI) equipment
- Pharmaceutical blister packaging machines
- Micro-dispensing systems for electronics assembly
Installation note:
Use precision alignment jigs during mounting to ensure parallel rail installation (max 0.05mm/m misalignment tolerance). Apply 32# turbine oil if used in high-cycleduty applications (>5Hz). Avoid side-impact loads exceeding 150N.
| Property | Property Value |
|---|---|
| sku | HLS12X20SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
