Airtac HLS Precision Slide Cylinder HLS12X20SB
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X20SB Precision Slide Table Cylinder Specifications
- Model: HLS12X20SB
- Type: Guided precision slide cylinder with linear bearing
- Bore size: 12mm
- Stroke: 20mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.7 MPa
- Cushion type: Adjustable rubber bumper (both ends)
- Mounting style: Side flange base (standard)
- Guide rail type: Dual linear ball bearings
- Repeat positioning accuracy: ≤±0.01mm
- Max sliding speed: 0.5 m/s
- Temperature range: -10℃ to 60℃
- Main materials: Aluminum alloy body, hardened steel guide rods
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Weight: 0.82kg (without accessories)
- Dimensions: 100mm(L) × 40mm(W) × 50mm(H) (at full retraction)
- Rod end thread: M6x1 internal thread
- Lubrication: Pre-lubricated (Grease life: 3,000km travel)
Ultra-compact guided cylinder combining pneumatic actuation with precision linear motion control. Features dual-axis anti-rotation design and hardened steel guide rods for exceptional lateral load capacity (max 10N·m moment resistance). Integrated T-slot mounting grooves enable modular tooling attachments. Optimized for cleanroom use with low particle generation.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Micro-dispensing systems in pharmaceutical production
- Automated optical inspection (AOI) scanners
- Semiconductor wafer handling robots
Installation note:
Maintain 0.02mm/m alignment tolerance during mounting. Use 5µm filtered dry air with 1-3 drops of ISO VG32 oil per m³.
For vertical installations, reduce payload by 30% from horizontal rating.
| Property | Property Value |
|---|---|
| sku | HLS12X20SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
