Airtac HLS Precision Slide Cylinder HLS12X30S
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X30S Precision Slide Table Cylinder Specifications
- Model: HLS12X30S
- Type: Dual-axis precision guided cylinder
- Bore size: Ø12mm
- Stroke: 30mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting: Side/Base mounting with M4 threaded holes
- Rod material: Stainless steel (SUS304)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.35kg (excluding accessories)
- Dimensions: 80mm(L) × 32mm(W) × 32mm(H)
- Repeat positioning accuracy: ±0.01mm
- Max lateral load capacity: 1.5N·m
- ISO standard: 15552 compliant
A high-rigidity linear actuator combining air cylinder and linear guide structure, featuring ultra-low friction (0.003–0.01 dynamic friction coefficient). Integrated guide rails with preloaded ball bearings ensure smooth motion and zero backlash. Requires 5μm filtered dry air with ISO VG32 lubrication.
- Precision alignment in semiconductor wafer handling
- Optical lens positioning systems
- Micro-dispensing equipment in PCB manufacturing
- Laboratory automation sample positioning
- Medical device assembly with cleanroom requirements
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. Use anti-vibration washers on mounting screws.
For vertical installations, add 20% extra thrust margin. Lubricate through air supply at 1 drop/5m³ airflow.
| Property | Property Value |
|---|---|
| sku | HLS12X30S |
| External Stop Block Type | No External Stops |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
