Airtac HLS Precision Slide Cylinder HLS12X30SA
The AirTAC Airtac HLS Precision Slide Cylinder HLS12X30SA is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLS Precision Slide Cylinder HLS12X30SA
The AirTAC HLS12X30SA is a double-acting dual-rod slide-table cylinder that integrates a cross-roller linear guide with an air cylinder. The cross-roller guide delivers high precision, rigidity, and low deflection, while the dual rods provide moderate thrust for a 12 mm bore at a 30 mm stroke. A floating joint protects the rods from side torque, and adjustable rubber stoppers at both ends let you fine-tune end-of-stroke positioning.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing with CMSH, DMSH, or EMSH switches. We confirm thrust, dimensions, and load-moment values from the AirTAC datasheet or on-page spec table on request.
Airtac HLS Precision Slide Cylinder HLS12X30SA Technical Specifications
| Model | Airtac HLS Precision Slide Cylinder HLS12X30SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLS (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 suits applications needing moderate thrust; a larger bore gives more push. The HLS cross-roller guide is chosen when maximum precision, rigidity, and load capacity matter most - it outperforms the HLQ ball-bearing guide in deflection resistance, though HLQ offers better corrosion and dust resistance. Stroke 30 mm falls within the bore 12 range. The A adjustable rubber stopper lets you set end-position cushioning at both ends. PT thread is standard; specify G or NPT if needed. Contact us to confirm allowable load, moment, and kinetic energy from the published tables and deflection curves.
Applications
Pick-and-Place Head
Cross-roller precision positions small parts during pick-and-place cycles with repeatable accuracy at 30 mm stroke.
Small-Parts Transfer
Transfers components between conveyor stations with straight guided travel and bumper cushioning at each end.
Assembly Stage Slide
Presents a workpiece to an assembly head with rigid cross-roller guidance that resists deflection under tooling load.
FAQ
What does the A adjuster code mean on HLS12X30SA?
A adds adjustable rubber stoppers at both the extension and retraction ends, letting you fine-tune end-of-stroke positioning. Shock-absorber options (B, BS, BF) are also available on bore 12 but not on bore 6.
What is the maximum operating pressure for the HLS12 cross-roller slide table?
Maximum working pressure is 0.7 MPa (100 psi). Bore 12 operates from 0.15 to 0.7 MPa (22-100 psi). Keep speed within 50-500 mm/s using meter-out flow control.
