Airtac HLS Precision Slide Cylinder HLS12X30SAS
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X30SAS Precision Slide Cylinder Specifications
- Model: HLS12X30SAS
- Type: Compact guided slide cylinder with integrated linear guide
- Bore size: 12mm
- Stroke: 30mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Piston rod material: Stainless steel SUS304
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: 0.42kg (excluding accessories)
- Dimensions: 130mm(L) × 34mm(W) × 34mm(H)
- Mounting: Dual M4 threaded holes (side/face mounting)
- Air port: M5x0.8 (Rc1/8 adaptor optional)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if replenished)
Ultra-precision slide cylinder combining pneumatic actuation with linear guide technology, delivering micron-level repeatability. Features dual-axis anti-rotation design and built-in shock absorption, optimized for high-speed reciprocation. Integrated T-slot allows modular fixture attachment.
- Semiconductor wafer handling robots
- Laser engraving equipment Z-axis control
- Micro-dispensing systems in PCB assembly
- Optical lens alignment mechanisms
- High-speed sorting machine pushers
Installation note:
Maintain 0.05mm maximum misalignment during mounting. Use only in clean air supply (40μm filtration).
For vertical installations, reduce speed to 300mm/s max to prevent seal wear. Periodic lubrication cycle:
2,000km travel distance or 6 months.
| Property | Property Value |
|---|---|
| sku | HLS12X30SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
