Airtac HLS Precision Slide Cylinder HLS12X30SB
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X30SB Precision Slide Table Cylinder Specifications
- Model: HLS12X30SB
- Type: Dual-axis guided precision cylinder
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Repeat positioning accuracy: ≤±0.01mm
- Maximum lateral load: 3.5N·m
- Maximum moment load: 2.0N·m
- Mounting orientation: Any (horizontal recommended for heavy loads)
- Seal material: Polyurethane (PU) with wear-resistant rings
- Temperature range: -20℃ to 80℃
- Weight: 380g ±5% (without accessories)
- Dimensions: 104mm(L) × 34mm(W) × 34mm(H) (full extension)
- Rod end thread: M6×1.0 internal thread
- Buffer type: Adjustable rubber cushioning (both ends)
- Lubrication: Pre-lubricated (Grease-free operation possible)
High-rigidity slide cylinder with dual linear guide rails and precision ground shafting, delivering micron-level positioning repeatability. Features anti-corrosion aluminum alloy body and chromium-plated piston rod (HRC45 hardness). Integrated T-slot design allows direct mounting of sensors or tooling plates. Compatible with ISO 6432 mounting accessories.
- PCB component insertion machines
- Laser marking equipment positioning stages
- Micro-dispensing systems in medical device assembly
- Optical inspection station slide mechanisms
- 3D printer Z-axis precision adjustment
Installation note:
Use alignment jigs during mounting to prevent guide rail binding. For vertical installations exceeding 45° angle,
reduce maximum speed by 30% and install an external shock absorber for strokes over 50mm.
| Property | Property Value |
|---|---|
| sku | HLS12X30SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
