Airtac HLS Precision Slide Cylinder HLS12X30SBS
$235.65
Regular price
$243.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLS12X30SBS
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated cross roller guide and cylinder design ensures high-strength, high-precision operation with exceptional load capacity, featuring superior linearity and anti-rotation accuracy for precision assembly applications;
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
Installation tips:
Maintain 0.05mm parallelism tolerance between guide rods and mounting surface.
Lubricate guide shafts every 50km of travel using silicone-free grease.
2. Pre-machined positioning pin holes integrated into guide rail;
3. Floating joint design prevents piston rod from bearing additional load moments;
4. Dual piston rod configuration delivers double output force;
5. Built-in positioning pin holes on main body;
6. Mounting screw holes on both base surface and end faces for versatile installation.
Category: Precision Slide Cylinder , Brand: AIRTAC , Series: HLS
AirTAC HLS12X30SBS Precision Slide Table Cylinder Specifications
- Model: HLS12X30SBS
- Type: Dual-axis guided slide cylinder
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 60℃
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting: Through-hole M4×4 (ISO 10298 compliant)
- Guide rod: Chrome-plated steel Ø6mm
- Repeat accuracy: ±0.01mm
- Max speed: 500mm/s
- Port size: M5×0.8 (standard)
- Seal material: NBR + PU hybrid seals
- Protection rating: IP54
- Weight: 480g (±2%)
-
Dimensions:
• Body: 100mm(L) × 34mm(W) × 34mm(H)
• Total stroke length: 130mm
Ultra-compact linear actuator combining pneumatic cylinder and precision linear guide in one unit. Features zero-backlash ball bearing guides and anti-rotation mechanism for stable vertical/horizontal operation. Requires 5μm filtered dry air with ISO VG32 lubricant (not included).
Ideal Applications:
- PCB component placement machines
- Lens positioning in optical inspection systems
- Micro-dispensing robots
- Semiconductor wafer handling
- 3D printer Z-axis calibration mechanisms
Installation tips:
Maintain 0.05mm parallelism tolerance between guide rods and mounting surface.
Lubricate guide shafts every 50km of travel using silicone-free grease.
Critical note:
Avoid side-load exceeding 2N·m. For vertical mounting,
always use counterbalance valve (AV-02 accessory recommended).
| Property | Property Value |
|---|---|
| sku | HLS12X30SBS |
| External Stop Block Type | Front Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
