Airtac HLSL Precision Slide Table Cylinder HLSL12X100S
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X100S is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X100S
The HLSL12X100S is a symmetrical double-acting dual-rod slide table cylinder with a cross-roller linear guide integrated into the body. The symmetrical design allows mounting in orientations where center of gravity matters, and the cross-roller guide delivers high precision, rigidity, and low deflection. Bore 12 provides higher thrust than smaller bores while keeping the footprint compact. The floating joint protects the rod from side torque.
This genuine AirTAC part includes a standard magnet for position sensing with CMSH, DMSH, or EMSH switches. The basic adjuster uses bumpers at both ends. We confirm thrust, dimensions, and load-moment values from the datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X100S Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X100S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 provides higher thrust for moderate-load applications; choose a larger bore if more push is needed. The HLSL cross-roller guide matches the HLS in precision and rigidity but adds a symmetrical body for balanced mounting. Stroke 100 mm is within the bore 12 range. The basic adjuster uses rubber bumpers; for shock absorption, consider B, BS, or BF options (not available on bore 6). Thread is PT as standard. We can confirm allowable load, moment, and deflection from published tables and curves.
Applications
Assembly Stage Positioning
Position a workpiece on the symmetrical slide table for repeatable assembly operations where the cross-roller guide keeps travel precise over the full 100 mm stroke.
Lateral Gripper Traverse
Move a gripper assembly sideways between two pick points with the dual-rod design providing stable thrust and the symmetrical body balancing the load.
Adjustable Stopper Slide
Use the basic bumper cushioning for a stopper mechanism where end-of-stroke positioning is handled by external fixtures and the slide provides straight guided travel.
FAQ
How does the HLSL symmetrical version differ from the HLS?
The HLSL has a symmetrical body layout, which allows more flexible mounting orientations and balanced load distribution. Both use the same cross-roller guide type and share the same bore, stroke, and thrust characteristics.
What pressure range applies to the HLSL12X100S?
Bore 12 operates at 0.15-0.7 MPa (22-100 psi), with a maximum working pressure of 0.7 MPa. Proof pressure is 1.2 MPa. Use meter-out speed control up to 500 mm/s.
