Airtac HLSL Precision Slide Table Cylinder HLSL12X100SA
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X100SA is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X100SA
The HLSL12X100SA is a symmetrical double-acting dual-rod slide table cylinder with a cross-roller linear guide. The symmetrical body supports balanced mounting, while the cross-roller guide provides high precision, rigidity, and minimal deflection. Bore 12 delivers higher thrust for moderate loads, and the dual rod doubles the force output. The floating joint prevents side torque from reaching the rod.
This genuine AirTAC part comes with a standard magnet and magnetic-switch slots for CMSH, DMSH, or EMSH sensors. The A adjuster adds adjustable rubber stoppers at both ends for fine end-position tuning. We confirm thrust, dimensions, and load-moment values from the datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X100SA Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X100SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 suits moderate-thrust applications; step up to bore 16 or 20 for more push. The HLSL cross-roller guide offers the highest rigidity in the HL family with a symmetrical body for balanced installation. Stroke 100 mm is within the bore 12 range. The A adjuster provides adjustable rubber stoppers at both ends for position fine-tuning; for shock absorption, consider B, BS, or BF codes. Thread is PT. Route load and moment sizing to us using published tables and curves.
Applications
Component Staging Slide
Stage components at a precise adjustable stop position on the assembly line, using the rubber stoppers to fine-tune the end of travel for repeatable placement.
Precision Test Fixture
Move a test probe or sensor into position against the workpiece with the cross-roller guide ensuring straight travel and the adjustable stoppers setting the contact point.
Alignment Station
Push a part into alignment using the symmetrical slide table where the dual rod provides stable thrust and the cross-roller guide keeps the motion precise and repeatable.
FAQ
What does the A adjuster code mean on the HLSL12X100SA?
A indicates adjustable rubber stoppers at both extension and retraction ends, letting you fine-tune the end positions. For shock absorbers instead, look for B (both ends), BS (extension side), or BF (retraction side) codes.
How are allowable load and moment confirmed for this model?
Allowable load, moment, and table deflection are published as spec tables and curves in the datasheet. We confirm these values on request so you can verify they meet your application requirements.
