Airtac HLSL Precision Slide Table Cylinder HLSL12X100SAF
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X100SAF Precision Slide Table Cylinder Specifications
- Model: HLSL12X100SAF
- Type: Dual-axis guided slide cylinder with magnetic piston
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable air cushion at both ends
- Repeat positioning accuracy: ±0.01mm
- Max thrust: 13.5N at 0.5MPa
- Max speed: 500mm/s
- Temperature range: -20℃ to 80℃ (non-freezing)
- Lubrication: Oil-free operation (pre-lubricated) or ISO VG32 compatible
- Mounting: Side-mount with M4x0.7 threaded holes
- Port size: PT1/8 (G1/8 optional)
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Guide rail: Precision ground steel with chrome plating
- Weight: 0.62kg (excluding accessories)
- Dimensions: 194mm(L) x 40mm(W) x 30mm(H)
A high-rigidity linear actuator combining pneumatic power with mechanical guidance, featuring dual hardened steel rails for exceptional moment resistance. The integrated magnetic piston enables position feedback when paired with standard cylinder sensors. Anti-rotation design maintains orientation stability during multi-axis operations.
- Precision alignment in semiconductor wafer handling
- Linear positioning for optical lens coating systems
- Automated inspection equipment stages
- Medical device assembly with cleanroom requirements
- 3C product testing machinery
Installation note:
Ensure rail surfaces are lubricated with light machine oil before initial use.
Avoid lateral overload exceeding 4.9N·m. For vertical mounting,
use counterbalance valves to prevent unexpected movement.
| Property | Property Value |
|---|---|
| sku | HLSL12X100SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
