Airtac HLSL Precision Slide Table Cylinder HLSL12X100SAS
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X100SAS Precision Slide Table Cylinder Specifications
- Model: HLSL12X100SAS
- Type: Double-rod cylinder with integrated linear guide
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.8 MPa
- Cushioning: Adjustable air cushion (both ends)
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, hardened steel rods (CrMoV)
- Port size: M5x0.8 (dual ports at both ends)
- Built-in sensor: Magnetic reed switch (2-wire NPN/PNP optional)
- Weight: 0.82kg (without accessories)
- Dimensions: 200mm(L) × 42mm(W) × 34mm(H) (at mid-stroke)
- Mounting: Standard M4 threaded holes on base (4 places)
- Lubrication: Pre-lubricated (ISO VG32 compatible)
High-precision linear actuator combining pneumatic power with guided motion control. Features zero-clearance roller bearings and scrape-resistant anodized surfaces. The dual-rod design eliminates rotational torque for ultra-stable linear movement. Integrated T-slot on table surface allows modular tooling attachments.
- Semiconductor wafer handling robots
- Laser engraving X-Y positioning systems
- Precision dispensing equipment
- Microscope stage automation
- Optical fiber alignment mechanisms
- PCB inspection machine feeders
Installation note:
For maximum accuracy, mount on Class 5 flatness surface. Lubricate guide rails every 50km of travel.
Sensor cables should be routed separately from power lines to prevent EMI interference.
- Max thrust: 7.2kgf @0.5MPa
- Max speed: 500mm/s (with cushion adjustment)
- Lateral load capacity: 15N
- Magnetic sensor actuation distance: 3mm max
| Property | Property Value |
|---|---|
| sku | HLSL12X100SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
