Airtac HLSL Precision Slide Table Cylinder HLSL12X100SB
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X100SB is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X100SB
A slide-table cylinder integrates an air cylinder with a linear guide so the moving table travels straight. This HLSL12X100SB is a symmetrical cross-roller dual-rod slide table with bore 12 mm and 100 mm stroke. The cross-roller guide gives high precision and rigidity with low deflection, and the dual rod doubles thrust. A floating joint spares the rod from side torque. The B adjuster adds shock absorbers on both ends for smoother end-of-stroke deceleration.
This is a genuine AirTAC part. A magnet is standard, and sensor switches CMSH, DMSH, and EMSH fit the magnetic-switch slots on the body. We confirm thrust, dimensions, load, and moment from the datasheet or on-page table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X100SB Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X100SB |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 gives moderate thrust for moving small to mid-size workpieces; choose a bigger bore if you need more push. The HLSL cross-roller guide suits applications needing maximum precision and rigidity. Stroke 100 mm is within the bore 12 range. The B option adds shock absorbers on both ends for smoother deceleration at higher moving loads; B-type adjusters are available on bore 12 and larger, not on bore 6. Thread is PT. For load and moment sizing, we route you to the published tables and deflection curves.
Applications
Pick-and-Place Head
Mounts a gripper for precise pick-and-place of small parts with shock-absorber deceleration at both stroke ends.
Assembly Stage Slide
Positions a workpiece at an assembly station with dual-rod thrust and cross-roller guide straightness.
Parts Transfer Gate
Actuates a transfer gate between conveyor lines with a 100 mm stroke and shock absorbers for smooth stops.
FAQ
What does the B adjuster code mean on HLSL12X100SB?
B indicates shock absorbers fitted on both ends for smoother end-of-stroke deceleration. B-type adjusters are not available on bore 6 but are supported on bore 12 and larger.
What is the maximum operating pressure for bore 12?
The maximum working pressure is 0.7 MPa. For bore 12 the operating range is 0.15 to 0.7 MPa (22 to 100 psi). Meter-out speed control keeps travel at or below 500 mm/s.
