Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBF
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBF is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBF
The HLSL12X100SBF is a genuine AirTAC double-acting dual-rod slide-table cylinder that integrates an air cylinder with a cross-roller linear guide. The cross-roller guide delivers high precision and rigidity with low deflection, while the dual rod doubles thrust and a floating joint protects the rod from side torque. Bore 12 mm and 100 mm stroke make this model suited to longer-travel pick-and-place and transfer tasks where guided accuracy matters.
This is a symmetrical-body variant of the HLS series. The magnet is standard, and sensor switches CMSH, DMSH, or EMSH mount in the body slots. The BF adjuster adds a shock absorber at the retraction side to soften end-of-stroke impact. Thread is PT. We confirm exact thrust, dimensions, and allowable load/moment from the published datasheet or on-page table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBF Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 12 mm bore gives moderate thrust for a compact guided slide; a larger bore in the same series increases push and pull. Choose the HLS cross-roller guide when precision and rigidity outweigh cost, or select HLQ ball-bearing for anti-rust dust-proof duty. Stroke 100 mm sits within the bore-12 range; select the BF shock-absorber option at the retraction side when end-stop energy is high. Load and moment sizing should be confirmed from the published tables and deflection curves - contact us for the correct values.
Applications
Pick-and-Place Head
Mounts a small gripper for precise pick-and-place of electronic components on a 100 mm guided travel path.
Part Transfer Stopper
Transfers small parts between conveyor lanes with the cross-roller guide keeping deflection low over the full stroke.
Assembly Stage Slide
Positions a sub-assembly head along the 100 mm stroke with shock-absorber cushioning at the retract end.
FAQ
What does the BF adjuster code mean on this HLSL model?
BF adds a shock absorber at the retraction side only, softening the impact at the retract end of stroke. The extend side keeps the standard bumper. This is an HLS/HLQ-only option and is available on bore 12 and above.
What is the maximum working pressure for the HLSL12 series?
Maximum working pressure is 0.7 MPa. Operating pressure for the 12 mm bore is 0.15-0.7 MPa (22-100 psi). Never exceed 0.7 MPa; proof pressure is 1.2 MPa for validation only.
